steel coil definition and classification
Steel coil- a finished steel product such as sheet or strip which has been wound or coiled after rolling. In the light of experience gained during these years, ANSON classifies steel coils into hot and cold- rolled types, or stainless steel coil, carbon coil and Galvanized Steel according to current products and international standards.
Hot-rolled coil is produced from semi-finished products , which are reduced to certain thicknesses by rolling and annealing and wound into a roll. Hot-rolled steel is used e.g. for the manufacture of pipes, steel doors and tanks or is further processed into cold-rolled steel.
Cold-rolled sheet in coil form is produced by removing rust from hot-rolled sheet by "pickling" it in a weak acid solution, then washing, brushing, drying, oiling and unrolling the sheet and finally performing cold-rolling by passing the sheet through a reducing mill under pressure and winding it into a roll. Cold-rolled steel is a more highly finished product and has a smoother surface, greater dimensional accuracy (thickness, width, length) and greater strength. Much cold-rolled steel is processed in the automotive industry, but some is also used in the manufacture of household goods.
Stainless steels are distinguished from carbon steel by their chromium content and, in certain cases - nickel. Adding chromium to carbon steel makes it more rust and stain-resistant, and when nickel is added to chromium stainless steel it enhances its mechanical properties, for example its density, heat capacity and strength. Stainless steel sheet is used, for example, in the manufacture of machinery, tools and containers.
Carbon coil, a type of steel that generally has only a small quantity of elements other than carbon, silicon, manganese, sulfur and phosphorus, so it has no significant alloying element. Carbon coil is good for second grade applications placing no particular demands on surface quality. ANSON’s carbon coil steel comes in a variety of grades and thicknesses to support the countless applications of this metal. We offer carbon coil in hot rolled, cold rolled, galvanized, aluminized and painted. Available grades include CS-B, FS -B, DS-B, DDS, EDDS, A36, SS Grades 30-55, A572-50 HSLA Grades 40-80 and A606.
|Available Alloys||1008, 1010 and other low carbon alloys|
|Thickness||0.002 – 0.035” (.0508 – .889mm)|
|Width||0.09 – 24” (2.286 – 609.6mm)|
|Tempers||Annealed, Hard as Rolled, Full Hard|
|Finishes||Coated, Uncoated, plated|
Galvanized coil produced when hot or cold rolled sheet or strip is coated with zinc, either by the hot-dipping or electrolytic deposition processes. Zinc coating applied by the hot dip method is normally heavy enough to resist corrosion without additional protective coating. Materials electronically galvanized are not used for corrosion-resistant applications without subsequent chemical treatment and painting, except in mild corrosive conditions, due to the thin coating of zinc. Galvanize is a pure zinc coating. A special heat-treating process converts the pure zinc coating to a zinc/iron alloy coating, and the product is known as Galvanneal. Galvanized sheet is used, e.g. in the automotive industry or in the production of roofing materials (e.g. flashing, guttering).
|Commercial Quality||Drawing Quality|
|Zinc Coating (gsm)||80-275||80-275|
|Coil ID (mm)||508||508|
|Coil Weight (max)||5.0 MT||5.0 MT|
|Bend Test at 180 deg Angle||0 t||0 t|
