330 stainless steel plate

330 Stainless Steel Plate

Chemical Composition (%) of 330 Stainless Steel Plate

Chromium	Nickel	Carbon	Silicon	Manganese	Phosphorus	Sulfur	Copper
18.00-22.00	34.00-37.00	0.08 max	1.00-1.50	2.00 max	0.03 max	0.03 max	1.00 max

Mechanical Properties of 330 Stainless Steel Plate

Tensile Strength – ksi (min.)	0.2% Offset Yield Strength – ksi (min.)	Elongation in 2 inches – % (min.)	Hardness – Rockwell B
70	30	30	90

Physical Properties of 330 Stainless Steel Plate

Density (lb. / cu. in.)	Specific Gravity	Specific Heat (Btu/lb Deg F – [32-212 Deg F])	Magnetic Permeability	Modulus of Elasticity Tension
0.289	7.99	0.11	1.02	28.5

330 stainless steel is an austenitic heat and corrosion resisting alloy that offers a combination of strength and resistance to carburization, oxidation and thermal shock. This alloy was designed for applications in high temperature industrial environments where good resistance to the combined effects of carburization and thermal cycling are required, such as the heat treat industry. Carburization and oxidation resistance to about 2100°F are enhanced by the silicon content of the alloy.

330 stainless remains fully austenitic at all temperatures and is not subject to embrittlement from sigma formation. It has a solid solution composition and is not hardenable by heat treatment.
