347 stainless steel plate

347 Stainless Steel Sheet Supplier

Chemical Composition (%) of 347 Stainless Steel Plate

Chromium	Nickel	Carbon	Silicon	Manganese	Phosphorus	Sulfur	Nitrogen
17.00-19.00	9.00-13.00	0.08 max	0.75	2.00 max	0.045 max	0.03 max	-

Mechanical Properties of 347 Stainless Steel Plate

Yield Strength 0.2% Offset		Ultimate Tensile Strength		Elongationin 2 in.	Hardness
psi (min.)	(MPa)	psi (min.)	(MPa)	% (min.)	(max.)
30,000	205	75,000	515	40	201 Brinell

Physical Properties of 347 Stainless Steel Plate

Density (lb. / cu. in.)	Specific Gravity	Specific Heat (Btu/lb Deg F – [32-212 Deg F])	Melting Range	Modulus of Elasticity
0.288	7.96	0.12	2550 – 2635°F	28.0 x 10⁶psi 193 GPa

Type 347 is a stabilized austenitic stainless steel similar to type 304 with an addition of Columbium and Tantalum. The columbium serves to produce a stabilized type of stainless steel which is immune to chromium carbide precipitation. This type of grades are thus recommended for parts fabricated by welding which cannot be susequently annealed or for parts which must operate in service between 800 – 1600°F.

Alloy 347 stainless steel plate exhibits good general corrosion resistance that is comparable to 304. It was developed for use in the chromium carbide precipitation range of 800 – 1600°F (427 – 816°C) where un-stabilized alloys such as 304 are subject to intergranular attack. In this temperature range, the overall corrosion resistance of Alloy 347 stainless steel plate is superior to Alloy 321 stainless steel plate. Alloy 347 also performs somewhat better than Alloy 321 in strongly oxidizing environments up to 1600°F (816°C).
