410S stainless steel

Chemical Composition (%) of 410S Stainless Steel Plate

C	Mn	Si	P	S	Cr	Ni
0.08	1.0	1.0	0.04	0.03	11.5-14.5	0.60

Mechanical Properties of 410S Stainless Steel Plate

Tensile Strength MPa (min)	Yield Strength 0.2% MPa(min)	Elongation (% in 50mm) min	Hardness (Rockwell B) MAX
444	290	33	75

Physical Properties of 410S Stainless Steel Plate

Density lb_m/in³	Thermal Conductivity (BTU/h ft. °F)	Electrical Resistivity (in x 10^-6)	Modulus of Elasticity (psi x 10⁶	Coefficient of Thermal Expansion (in/in)/ °F x 10^-6	Specific Heat (BTU/lb/ °F)	Melting Range (°F)
at 68°F: 0.280	187 at 212°F	23.7 at 68°F	29	6.0 at 32 – 212°F	0.11 at 68°F to 212°F	2700 to 2790

Alloy 410S (UNS S41008) is a low carbon, non–hardening modification of Alloy 410 (UNS S41000) the general purpose 12% chromium martensitic stainless steel. The low carbon and a small alloy addition minimize austenite formation at high temperatures which restricts the alloys ability to harden.

410S remains soft and ductile even when rapidly cooled from above the critical temperature. This non-hardening characteristic helps prevent cracking when the alloy is exposed to high temperatures or welded. 410S is completely ferritic in the annealed condition. It exhibits adequate corrosion resistance similar to 410 and good oxidation resistance.
